XCMG XGC55 Crawler Crane

Covering a wide range of vehicle models including dump trucks, tractors, etc., we provide a full-process car buying experience with a mature sales team, remote technical services and after-sales guarantees. For detailed consultation, please feel free to contact us online at any time.



+86 532 86998158



Lizihao@cnxiangcai.com

Classification

Hoisting Machinery

PRODUCT DESCRIPTION

XCMG crawler crane XGC55 is designed and developed independently in absorption of foreign advanced technology and combined with China domestic work conditions.

Optimized hydraulic system design
Integrated design to reduce failure points, while reserve open space for assembly/ disassembly and maintenance. Use of highly integrated LUDV main valve, with the functions of multi-com- plex operation, control of combined flow, high/low speed selection, to ensure operation efficiency. Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.

Main/ auxiliary hook one-key-switch-over function
One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.

Universal and modular design

Common platform products with fixed jib, single top, both-sided counterweight, luffing mechanism, hydraulic pump and main valve block can achieve universal and interchangeable use, greatly reduce purchase, transport and maintenance costs.

Item	Unit	Parameters
Rated lifting capacity
Boom working condition	t	55
Boom single pulley working condition	t	6
Fixed jib working condition	t	11.4
Load moment
Max. Load moment	t.m	203.5
Dimension
Max. size of single unit for transport (L×W×H)	m	12.04×3.45×3.36
Main boom length	m	13~52
Main boom luffing angle	°	-3~80
Fixed jib length	m	7~16
Speed
Max. single line speed of hoist system	m/min	125
Max. single line speed of main luffing system	m/min	87
Max. slewing speed	r/min	2.45
Max. travel speed	km/h	1.37
Gradeability	%	30
Power
Engine Model	/	SC7H210.1G3
Engine rated power	kW/(r/min)	155/2000
Weight
Total vehicle mass	t	46.3
Max. Mass of single unit in transport state	t	28.6
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice
